“HSK” series
Combi, multi energy tanks of fresh water technology with one heat exchanger dedicated to solar energy. An efficient solution for space heating support using the energy of the sun and at the same time production of domestic hot water.
Tank is divided in two compartments optimizing the stratification. All available energy sources can be connected to the tank such as solar, heat pump, biomass, gas etc.
The domestic water is produced instantaneous through a 316L stainless steel heat exchanger, eliminating the possibility of the legionella bacteria. The heat exchanger is divided in 2 parts offering recirculation options.
The tank has been tested and certified according to European Directives (LVD 2014/35EU, ECD 2014/30/EU, PED 2014/68/EU, RoHS 2011/65/EU, ERP 2013/812/EU, Ecodesign 2013/814/EU).
"HSK" Series
OPTIONS
ELECTRICAL RESISTANCE CONNECTION
"HSK" Series
SPECIFICATIONS
| HSK 390 PR | HSK 600 PR | HSK 750 PR | HSK 1000 PR | HSK 1700 PR | ||
| Energy efficiency | C | – | – | – | – | |
| Internal diameter | mm | 550 | 650 | 750 | 800 | 1100 |
| External diameter | mm | 750 | 850 | 950 | 1000 | 1300 |
| Height | mm | 1905 | 1935 | 1975 | 2080 | 2075 |
| Area of upper water heat exchanger | m² | 6 | 6 | 6 | 6 | 6 |
| Area of lower water heat exchanger | m² | – | 3 | 3 | 3 | 3 |
| Capacity of upper heat exchanger | L | 21 | 21 | 21 | 21 | 21 |
| Capacity of lower heat exchanger | L | – | 11 | 11 | 11 | 11 |
| Heat exchanger area for sun | m² | 1,5 | 2,4 | 2,5 | 3,2 | 4 |
| Heat exchanger capacity for sun | L | 9 | 13 | 15 | 18 | 22 |
| Provisions of heat exchanger for water | Inch | 1” | 1’’ | 1’’ | 1’’ | 1’’ |
| Provisions of heat exchanger for sun | Inch | 1” | 1’’ | 1’’ | 1’’ | 1’’ |
| Provision of free benefits | Inch | 1” | 1 1/2’’ | 1 1/2’’ | 1 1/2’’ | 1 1/2’’ |
| Provision electrical resistance | Inch | 1 1/2” | 1 1/2’’ | 1 1/2’’ | 1 1/2’’ | 1 1/2’’ |
| Provide of ventilation | Inch | 1/2” | 1/2” | 1/2” | 1/2” | 1/2” |
| Sensory provision | Inch | 1/2” | 1/2” | 1/2” | 1/2” | 1/2” |
"HSK" Series
DIMENSIONS
HSK390PR
HSK600PR
HSK750PR
HSK1000PR
HSK1700PR
"HSK" Series
RELEVANT DOCUMENTS
BROCHURES
Διαφημιστικό Φυλλάδιο / Advertisement Brochure HSK-DUO
INSTRUCTIONS
Οδηγίες Εγκατάστασης / Installation manual HSK600-1700PR
Οδηγίες Εγκατάστασης / Installation manual HSK390PR
