SAMMLER series XS-LPNV
XS300-50LP
Only the best is good enough!
The XS-LP solar water heater combines advanced technology with flexibility, offering the option to connect to a heat pump for maximum energy savings.
The XS300-50LP model features a 300-liter tank and a 5.04 m² selective collector, ensuring high efficiency and an ample supply of hot water. Its low-profile design allows installation in areas with limited available height, without compromising performance. The triple-energy tank integrates solar, electric, and thermal support, guaranteeing a stable supply of hot water throughout the year. The selective collector maximizes solar radiation absorption, delivering reliable operation even under low sunlight conditions.
300lt
Capacity
2
Collectors
10years
Warranty
SERIES XS300-42LP
OPTIONS
INSTALLATION OF SIDE COVERS
PLACEMENT OF ELECTRONIC ANODE ROD
FOR ADDITIONAL PROTECTION
SERIES XS300-42LP
SPECIFICATIONS
| SOLAR WATER HEATER SERIES XS-LP | |
|---|---|
| Model | XS300-50LP |
| Type | Closed circuit |
| Placement | 25° |
| Collectors number | 2ps |
| TANK | |
|---|---|
| Model | HP301-2 |
| Energy class | Β |
| Capacity | 311l |
| Heat exchanger type | mantle / spiral |
| Heat exchanger capacity | 14,55l |
| Heat exchanger capacity | 1,92 / 2,31 m² |
| Weight | 107kg |
| Internal protection | Thick enamel 250-350μm |
| Anti Corrosion protection | 2 Magnesium rod Ø22x400mm |
| Insulation | Polyurethane |
| Insulation thickness | 50mm |
| Insulation density | 42kg/m³ |
| Internal trunk material | S300EK AM FCE – 2,5mm |
| Heat exchanger construction material | S235JR – 1,5mm |
| Outer casing material | GRANITE® HDX – 0,5mm |
| Auxiliary source | Electrical resistance – 3,5kW |
| Connections | 3/4” Female thread |
| COLLECTOR | |
|---|---|
| Model | ARIS2504 |
| Total area | 5,04m² |
| Apperture area | 4,60m² |
| Absorber surface | 4,56m² |
| Weight | 90kg |
| Frame | Aluminum profile 1,3mm – RAL7038 |
| Collector’s back | Al 0,4mm |
| Absorber | ALANODE Mirotherm – 0,4mm |
| Absorption | 95% |
| Emmisivity | 5% |
| Header | Ø22mm |
| Risers | Ø8mm – 11ps |
| Solar crystal | 3,2mm — 91,8% absorption |
| Insulation | stone wool |
| Insulation thickness | 40mm |
| Insulation density | 40kg/m³ |
| SUPPORT BASE | |
|---|---|
| Model | SB300-LP |
| Construction material | Zn – 2,5mm |
| CONNECTION SET | |
|---|---|
| Model | IKEVO300/10 |
| Water safety valve | 10bar |
| Closed circuit safety valve | 3bar |
| Type of accessories | Brass- Mechanical tightening |
| Connecting pipes | Stainless flexible DN16 |
| Insulation | 9x22mm protection UV |
| Thermal medium | CLARIANT Antifrogen SOL HT |
| Quantity | 10l (100% condensation) |
SERIES XS300-42LP
DIMENSIONS
XS300/50LP
